Wholesale Supplier 100-600 GSM PP Needle Punch Geotextile
Wholesale supplier of 100–600 GSM PP needle punch geotextile for road construction, drainage filtration, and soil separation. Favourite Fab manufactures polypropylene needle punched nonwoven geotextile across the full GSM range with consistent tensile strength, puncture resistance, and hydraulic properties — available in bulk rolls for infrastructure contractors and geotechnical distributors across India and global markets.
PP Needle Punch Geotextile — Full GSM Range Specifications
| GSM | Tensile Strength (kN/m) | CBR Puncture (kN) | Water Permeability (m/s) | Typical Use |
|---|---|---|---|---|
| 100 | 7–9 | 0.9–1.2 | 5×10⁻³ | Separation, light drainage |
| 150 | 10–12 | 1.4–1.8 | 4×10⁻³ | Road subbase separation |
| 200 | 14–16 | 2.0–2.5 | 3×10⁻³ | Railway ballast, filtration |
| 300 | 20–25 | 3.0–3.8 | 2×10⁻³ | Embankment reinforcement |
| 400 | 28–34 | 4.5–5.5 | 1.5×10⁻³ | Retaining walls, slopes |
| 600 | 40–48 | 6.5–8.0 | 1×10⁻³ | Heavy-duty reinforcement |
Applications by Construction Type
- Road construction: 150–200 GSM for sub-grade separation prevents fines migration into aggregate base
- Railway projects: 200–300 GSM under ballast for filtration and load distribution
- Retaining walls: 300–400 GSM behind block/gabion walls for drainage and filtration
- Landfill lining systems: 300–600 GSM as protection layer over geomembrane
- Pond and canal lining: 200–300 GSM under HDPE liner to prevent puncture
- Coastal and erosion protection: 400–600 GSM for riprap underliner
Why Favourite Fab for Bulk Geotextile Supply
- Direct manufacturer — no middleman markup on wholesale orders
- Standard roll width: 4.5 m and 5.8 m (custom widths available)
- Roll length: 100 m standard (50 m, 200 m available)
- UV stabilised for outdoor storage up to 6 months
- BIS certification available for government tenders
- Export documentation: GST invoice, phytosanitary, COC, test reports
Frequently Asked Questions
- What GSM is required for NHAI road projects?
- MORTH specifications typically call for 150–200 GSM nonwoven geotextile for sub-grade separation. Check tender specifications — Favourite Fab can supply with test reports conforming to IS 17189.
- What is the minimum order quantity for wholesale pricing?
- Wholesale pricing applies from 5,000 sqm per GSM grade. Contact our sales team for project-specific quotes and staggered delivery schedules.
- Do you supply geotextile for metro rail projects?
- Yes. Favourite Fab has supplied needle punch geotextile to infrastructure contractors on metro projects in Agra, Lucknow, and Delhi NCR regions.
- Can you provide third-party test reports?
- Yes. All grades are tested at NABL-accredited labs. Test reports for tensile strength, CBR puncture, permeability, and UV resistance available with each shipment.
Get wholesale pricing on 100–600 GSM PP needle punch geotextile from Favourite Fab. Request bulk quote, project specification matching, and sample rolls for quality approval from our geotechnical supply team.
Technical Specifications
Favourite Fab manufactures PP needle-punch nonwoven geotextiles from 100 GSM to 600 GSM, conforming to IS 16392 and ASTM D4759. The needle-punch process creates a three-dimensional fibre matrix that delivers superior filtration, drainage, and separation performance compared to woven alternatives at equivalent mass.
| Parameter | Value |
|---|---|
| GSM Range | 100–600 GSM |
| Fibre Type | 100% Polypropylene (PP) staple fibre, needle-punched |
| Standards | IS 16392, ASTM D4759 |
| Wide-Width Tensile Strength | ≥ 20 kN/m (ASTM D4595, machine direction) |
| CBR Puncture Resistance | ≥ 2 kN (EN ISO 12236) |
| Apparent Opening Size (AOS) | 0.075–0.60 mm (grade-dependent) |
| Available Roll Width | 2.0 m, 4.0 m, 5.8 m |
| Roll Length | 50 m – 200 m per roll |
Higher GSM grades (400–600 GSM) are specified for heavy-duty separation and reinforcement in road sub-base construction, railways, and landfill lining systems. Mid-range grades (200–300 GSM) are widely used for drainage filtration behind retaining walls. Lighter grades (100–150 GSM) serve as protective cushion layers for HDPE geomembranes.
B2B Applications & OEM Use-Cases
- Road Sub-Base Separation for Highway Contractors: EPC firms and road contractors specify 200–300 GSM PP needle-punch geotextile as a separation layer between subgrade soil and aggregate base courses on NHAI, PMGSY, and state highway projects, preventing fines migration and extending pavement life.
- Retaining Wall Drainage & Filter Systems: Civil contractors building segmental retaining walls, MSE walls, and bridge abutments use 150–250 GSM needle-punch geotextile as a drainage filter layer, meeting ASTM D4759 filtration criteria for the specified backfill soil gradation.
- Landfill Liner Cushion & Leachate Collection: Environmental engineering firms designing MSW landfill liner systems procure 400–600 GSM needle-punch geotextile as a protective cushion above HDPE geomembranes and as a drainage/filter layer in leachate collection systems, requiring CBR puncture resistance ≥ 2 kN.
Sourcing from Favourite Fab — MOQ, Lead Time & Customisation
As a wholesale supplier and manufacturer, Favourite Fab offers PP needle-punch geotextiles across the full 100–600 GSM range with flexible roll dimensions and certification options suited to project-specific specifications.
- MOQ: 500 kg per GSM/width specification
- Domestic Lead Time: 7–14 working days from order confirmation
- Export Lead Time: 21–30 days (FOB / CIF as required)
- Custom Options: GSM, roll width (up to 5.8 m), roll length, IS 16392 / ASTM D4759 test certificates, third-party inspection, project-specific colour coding
- Quality Certifications: ISO 9001:2015; test reports covering tensile, CBR puncture, AOS, permittivity issued per production lot
Submit your project specification sheet or tender requirement for a batch-specific technical offer and quotation.
Frequently Asked Questions
What standards do your PP needle-punch geotextiles comply with?
Our PP needle-punch geotextiles are manufactured and tested to IS 16392 and ASTM D4759. Test parameters include wide-width tensile strength (ASTM D4595), CBR puncture resistance (EN ISO 12236), apparent opening size, and permittivity. Batch test certificates are issued with every supply.
How do I select the right GSM for my road or drainage project?
For road sub-base separation on NHAI/PMGSY projects, 200–250 GSM is most commonly specified. For drainage filtration behind retaining walls, 150–200 GSM with AOS matched to backfill soil is recommended. For landfill liner cushion, 400–600 GSM with CBR ≥ 2 kN is required. Our technical team provides grade selection support based on your subgrade CBR, backfill gradation, and design load.
Can you supply geotextile rolls in custom widths for large civil projects?
Yes. Standard roll widths are 2.0 m, 4.0 m, and 5.8 m. Custom widths can be accommodated for large volume orders (typically ≥ 5,000 kg). Roll lengths can also be specified per project requirement.
