Heat Sealable Nonwoven Fabric
Manufacturer India
PE/PP bico spunbond nonwoven fabric that seals cleanly on bar seal, ultrasonic, and impulse machines at 130C. No adhesives. No deformation. Available 20-80 GSM with custom width.
What Is Heat Sealable Nonwoven Fabric?
Heat sealable nonwoven fabric is a nonwoven material that can be bonded to itself or another layer using heat and pressure alone, without any adhesive. The sealing happens when the outer surface of the fabric melts slightly and fuses with the adjacent layer, forming an airtight, strong bond.
The most widely used heat sealable nonwoven is PE/PP bicomponent spunbond. The PE sheath melts at ~130C while the PP core stays solid at ~160C. This 30C gap creates a forgiving sealing window that works reliably across bar seal, ultrasonic, and impulse sealing machines.
This fabric is used wherever you need a fast, clean, adhesive-free seal in production. The primary applications are desiccant pouches, hygiene product covers, and filtration bags. See our full desiccant fabric range at silica gel packaging material.
Compatible with 3 Sealing Machine Types
Our heat sealable nonwoven works on every standard production sealing machine. No machine upgrades required.
Heated metal bar presses directly onto the fabric at 130-150C. Simple, fast, and reliable. Used in most desiccant pouch production lines. Compatible with all standard bar widths.
High-frequency vibration generates friction heat at the fabric interface. PE sheath melts and bonds without external heat contact. Produces the cleanest seal with no burn risk. Ideal for food and pharma grade pouches.
Electric impulse heats a nichrome wire element briefly. Fabric cools under pressure to form a strong bond. Good temperature control makes it suitable for thinner GSM fabrics and precise sealing requirements.
Full Specification Sheet
Standard specifications for heat sealable nonwoven fabric. Custom options available.
| Parameter | Specification |
|---|---|
| Material | PE/PP Bicomponent Spunbond – PP core + PE sheath |
| GSM Range | 20 GSM to 80 GSM |
| Available Width | 5.5 cm to 200 cm – custom widths on request |
| PE Sheath Melt Point | ~130C – bonds at seal temperature |
| PP Core Melt Point | ~160C – stays solid, maintains structure |
| Sealing Temperature | 130C to 150C |
| Sealing Pressure | 0.2 to 0.6 MPa (varies by machine and GSM) |
| Sealing Time | 0.5 to 2 seconds (bar seal typical) |
| Compatible Machines | Bar seal – Ultrasonic seal – Impulse seal |
| Surface | Smooth, uniform filament structure |
| Colour | White (standard) – Other colours on request |
| Packing | Roll form – core diameter customisable |
| Certifications | ISO – OEKO-TEX – REACH – FDA 21 CFR (food grade on request) |
Key Properties of Heat Sealable Nonwoven
Where Heat Sealable Nonwoven Is Used
Why Source From Us?
How to Order
3 steps from enquiry to shipment.
Request a Free Sample Today
We respond within 24 hours. Samples dispatched within 48 hours of spec confirmation.
Frequently Asked Questions
Related: non woven fabric vs tyvek for desiccant packaging and non woven rolls for automatic desiccant pouch packing machine.
