Electret PP Spunbond Filter Media for HVAC and Air Filtration Applications
Electret PP spunbond filter media delivers high particle filtration efficiency at a low pressure drop — the combination that defines commercial success for HVAC filters, air purifier elements, and cabin air filter cartridges.
Unlike mechanically dense filter media that achieve high efficiency by reducing pore size and increasing flow resistance, electret media uses a permanently embedded electrostatic charge to intercept fine particles at coarser fiber geometries.
Favourite Fab is a B2B upstream raw material supplier based in Agra, India, with over 10 years of nonwoven manufacturing experience and export capability to more than 50 countries.
We supply permanently corona-charged PP spunbond filter media in bulk rolls to HVAC OEMs, air purifier manufacturers, and automotive cabin filter makers at competitive wholesale pricing.
What Is Electret PP Spunbond Filter Media
Electret filter media is polypropylene spunbond nonwoven that has been permanently corona-discharged to embed a stable electrostatic charge within the fiber matrix.
During the corona treatment process, a high-voltage electric field is applied across the fabric, ionising the surrounding air and driving charge carriers deep into the semi-crystalline PP fiber structure.
This charge does not rely on an external power source or conductive additive — it remains active throughout the filter’s operational service life under normal temperature and humidity conditions.
The mechanism of filtration in electret media is fundamentally different from mechanical depth filtration.
Mechanical filtration captures particles by physical interception, inertial impaction, and diffusion — all of which improve as fiber diameter decreases and pore size tightens.
The electrostatic capture mechanism in electret media attracts charged and polarisable particles — including bacteria, fine dust below 1 µm, pollen, and combustion soot — through Coulomb and dielectrophoretic forces.
This allows the fabric to achieve filtration class M5 or M6 efficiency (EN 779 / ISO 16890 ePM2.5) while maintaining a low pressure drop compared to mechanical-only media at the same class.
Lower pressure drop delivers concrete commercial benefits across every electret filter application.
In HVAC air handling units, lower media resistance reduces blower motor energy consumption — a key metric in building energy codes such as ASHRAE 90.1 and EU ErP Directive.
For air purifier OEMs, low pressure drop at high airflow enables quieter fan operation at the same CADR output and reduces fan motor cost per unit.
For automotive cabin filter makers, electret media meets Class F5 or F6 performance targets with a lighter and thinner filter element than equivalent mechanical media, saving vehicle weight and cabin filter housing depth.
Electret PP Spunbond Filter Media — Specifications and Options
Favourite Fab supplies electret PP spunbond filter media from 50 GSM to 200 GSM.
Lighter grades (50–80 GSM) are used in face masks and thin-profile pleated HVAC elements where minimising media weight is a priority.
Mid-range grades (80–120 GSM) are the standard for pleated panel filters, bag filters, and air purifier filter cartridges.
Heavier grades (120–200 GSM) are used in high-dust-loading HVAC pre-filters and industrial panel filter applications.
Custom GSM, charge density, and surface treatment are available on request for specialised filtration applications.
| Parameter | Specification | Detail |
|---|---|---|
| Basis Weight (GSM) | 50 – 200 GSM | Grade selected by application: HVAC panel, air purifier, cabin filter, face mask |
| Particle Filtration Efficiency (PFE) | 85 – 99% @ 0.3 µm | Tested per EN 1822 or EN 779; efficiency is grade and GSM dependent |
| Pressure Drop | 20 – 80 Pa @ 0.053 m/s | Measured per EN 779 standard test velocity; grade and GSM dependent |
| Charge Type | Permanent corona electret | High-voltage discharge process; no conductive additive required in fiber |
| Fiber Diameter | 15 – 25 µm (PP) | Virgin polypropylene fiber; no recycled content in filter media grades |
| Width | 1,600 mm – 3,200 mm | Full-width rolls or slit to customer converting machine width on request |
| Filter Class (EN 779) | G3 / G4 / M5 / M6 | Filter class confirmed by third-party EN 779 test report; available on request |
| Filter Class (ISO 16890) | ePM10 / ePM2.5 / ePM1 | ISO 16890 classification available for European and export market specifications |
| Operating Temperature | Up to 80°C continuous | Short-term peak 100°C; confirm for high-temperature HVAC duct applications |
Applications for Electret PP Spunbond Filter Media
Understanding your end application allows Favourite Fab’s technical team to recommend the correct GSM, charge density, and fabric finish for your product.
Electret PP spunbond media is used across a wide range of air filtration products with distinct performance requirements.
HVAC air handling units: HVAC panel and bag filters at G3 to M6 class use electret media as the primary filtration layer or as a laminate over a structural support scrim. The combination of high dust holding capacity and low pressure drop extends service intervals and reduces operating energy cost per cubic metre of filtered air.
Residential and commercial air purifiers: Air purifier OEMs specify electret media for the main particulate filter stage (pre-HEPA stage) in multi-stage filtration units. Electret media captures PM2.5 and larger particles before the air reaches the HEPA stage, extending HEPA life and reducing total filter replacement cost for the end user.
Automotive cabin air filters: Cabin air filters in passenger cars and commercial vehicles use electret media to meet ISO 11155-1 or SAE J1669 filtration efficiency requirements. The lower pressure drop of electret media at Class F5/F6 efficiency versus mechanical media of the same class reduces HVAC blower power consumption — a relevant factor in electric vehicle range calculations.
Why Source From Favourite Fab
HVAC OEMs, air purifier manufacturers, and automotive cabin filter producers in over 50 countries source their filter media from Favourite Fab.
Here is what procurement and quality teams consistently identify as the key reasons they continue to work with us.
- MOQ-friendly: We supply both large-volume HVAC filter manufacturers consuming multi-tonne monthly quantities and smaller air purifier startups in development-stage production. MOQ is structured to fit your production cycle without requiring excess inventory commitment from smaller buyers.
- Export-ready: Full export documentation for every shipment — certificate of analysis, EN 779 or ISO 16890 test reports, MSDS, and customs paperwork — is prepared to the destination country’s import requirements. We have experience exporting to 50+ countries across Europe, Southeast Asia, the Middle East, and the Americas.
- ISO certified production: Our manufacturing facilities and corona charging process operate under ISO quality management systems. Batch traceability, charge uniformity validation, and COA documentation accompany every production roll.
- 10+ years of nonwoven expertise: Our team has been producing corona-charged nonwoven filter media for the HVAC and air purifier industry for over a decade. We understand filter element converting requirements and can support new product development qualification.
- Custom specifications: GSM, charge density, treatment level, width, and surface finish (calendered, rough, or laminated with support scrim) can be tailored to your filter class target and converting machine requirements.
- Charge stability validation: Our electret process is validated for charge retention under accelerated ageing per established protocol. This is critical for filter products with 12-month or longer shelf life requirements at distributor and retail level.
Pricing and MOQ
Favourite Fab offers competitive wholesale pricing for electret PP spunbond filter media.
Pricing per kilogram depends on GSM grade, roll width, charge density specification, order volume, and destination port.
We do not publish fixed price lists — all commercial quotations are issued based on your confirmed technical specification and volume requirement.
To receive a formal quotation, submit your target GSM, required filter class (EN 779 or ISO 16890), roll width, and confirmed monthly volume.
Our sales team responds within one business day with a formal commercial offer and sample dispatch timeline.
Qualification samples with EN 779 PFE and pressure drop test data are dispatched on your confirmation.
How to Order
- Submit your specification: Email sale@favouritehub.com with your target GSM, filter class requirement (EN 779 or ISO 16890), required roll width, and monthly volume. WhatsApp enquiries are also welcome at +91-9528811566 for faster initial contact.
- Receive samples and quotation: We dispatch sample rolls for your internal PFE and pressure drop qualification testing within the agreed timeframe. A formal commercial quotation covering pricing, lead time, and payment terms is issued at the same time as sample dispatch confirmation.
- Confirm and place your order: Once your quality team approves the sample performance data and you confirm the commercial terms, submit your purchase order. We issue a proforma invoice and schedule production to your confirmed delivery timeline and port of loading.
Frequently Asked Questions
Q: What is the difference between electret spunbond and meltblown filter media?
A: Meltblown uses extremely fine fibers (typically 1–5 µm diameter) to achieve high mechanical filtration efficiency through physical interception and inertial impaction. Electret spunbond uses coarser PP fibers (15–25 µm) that are corona-charged to capture particles electrostatically. Electret spunbond has significantly lower pressure drop and is more cost-effective for G3 through M6 filter classes. Meltblown is the standard for HEPA and ULPA grades where sub-micron particle capture requires the mechanical fine-fiber filtration mechanism.
Q: Does the electrostatic charge in electret media degrade over time?
A: The corona electret charge in PP fibers is stable under normal storage and operating conditions below 80°C. Charge retention is validated per accelerated ageing protocols — our standard grade maintains its rated PFE after accelerated ageing simulation of a 12-month shelf life. High sustained humidity, oil aerosol exposure, and temperatures above 80°C can progressively reduce the electrostatic contribution. Our technical team can advise on appropriate grade selection and storage conditions for your specific application environment.
Q: Which international test standards apply to electret PP spunbond filter media?
A: Key standards include EN 779 (EU; now largely superseded by ISO 16890 for HVAC applications), ISO 16890 (global current standard for HVAC filters, classifies by PM10/PM2.5/PM1 efficiency), ASHRAE 52.2 (North America; MERV rating system), and EN 1822 (for HEPA/ULPA efficiency testing). Favourite Fab can supply test reports against any of these standards through accredited third-party test laboratories. Specify your target standard at the quotation stage.
Q: Can Favourite Fab supply electret media for face mask filtration?
A: Yes. We supply lighter electret PP spunbond grades (50–80 GSM) for face mask filtration layers used in KN95, FFP2, and surgical-style masks. For mask applications, specify the target standard (GB2626 for KN95, EN 149 for FFP2, ASTM F2100 for surgical mask) and the required BFE and PFE performance levels so our team can match the correct charge density and fiber configuration.
Q: What roll dimensions and packaging format do you use for filter media shipments?
A: Standard filter media rolls are available in widths from 1,600 mm to 3,200 mm, slit to your converting machine width. Roll length and core diameter (76 mm or 152 mm standard) can be specified per your unwinding system. Rolls are packed in moisture-resistant polyethylene bags, labelled with roll number, GSM, width, and batch number, then palletised for container loading with weight and dimension dockets for customs clearance.
Q: Do you offer technical support for filter element design using electret media?
A: Our technical team provides pre-purchase consultation on media selection, pleat geometry parameters for HVAC panel filters, expected filter class performance based on your airflow velocity and efficiency targets, and guidance on converting machine setup for electret PP spunbond. We support the full qualification process from initial sample receipt through production approval at no additional charge for volume customers.
Contact Favourite Fab
Favourite Fab is a B2B upstream raw material supplier for nonwoven filter media and technical fabrics.
We export electret PP spunbond filter media to HVAC manufacturers, air purifier OEMs, automotive cabin filter producers, and face mask manufacturers across India, Southeast Asia, Europe, the Middle East, and the Americas.
Our ISO-certified manufacturing, export-ready documentation, and MOQ-friendly order structure make us a dependable upstream partner for air filtration product development and production.
Reach our sales and technical team today to request samples, an EN 779 or ISO 16890 data sheet, or a formal commercial quotation for your filter media requirement.
- Email: sale@favouritehub.com
- WhatsApp: +91-9528811566
- Website: favouritehub.com
Contact us now to receive a quotation and qualification sample rolls within one business day.
Our technical team will match the right electret PP spunbond grade to your filter class target, converting machine specification, and end-market standard requirement.
